Faster and more efficient processes by combining BPM and Mobile
A. Synopsis
What this is about
A lot has happened in the area of mobile since Apple kicked off the revolution by announcing the first iPhone. However, the overall mobile market still has to be considered as young and especially unstandardized. This really puts a lot of organizations in front of huge challenges concerning the efficient development of mobile applications and the secure integration into backend IT systems.
But there is no way around mobile in the next years! The smart combination of mobile techniques (MBaaS, micro services, etc.) and business process management approaches will definitely drive process efficiency and speed to a whole new level.
The use case or “What if the process was at the fingertips of your customer?”
This showcase addresses a scenario that almost all enterprises in the insurance industry are facing: nowadays users expect to be able to contact their insurance 24/7 on an ad-hoc basis (e.g. for opening a claim or just for asking a question concerning their policy). Additionally they want to see on demand what the status of a certain request is. From an enterprise point of view insurances are looking at new ways on reacting to this new speed of communication and transparency. They’re also thinking of new concepts to efficiently integrate agencies and remote workers in their existing processes. They key consequence to address these requirements is to enhance existing input & output management infrastructure by a newly established mobile channel.
In this showcase we used Red Hat Mobile Application Platform (https://www.redhat.com/en/technologies/mobile/application-platform) as a key building block to efficiently and securely connect the outside world with existing enterprise systems.
Through the platform approach we do not need to reinvent the wheel for each mobile app on the horizon. Instead we put in place a centralized platform for developing and running mobile application in a standardized manner.
The use of Red Hat Mobile Application Platform (RHMAP) comes with the following benefits:
- Agile approach to developing, integrating, and deploying enterprise mobile applications—whether native, hybrid, or on the web
- Out-of-the-box automated build processes (including build farm)
- A service catalog for reusable connectors to backends
- Easy scale-out through cloud native architecture
- Collaborative development across multiple teams and projects with a wide variety of leading tool kits and frameworks
Architectural overview
From a technical point of view the showcase is comprised of three main building blocks:
- CLIENT LAYER: Hybrid mobile applications running on the end user devices
- CLOUD LAYER: Node.js based backend running in the cloud on RHMAP
- BACKEND LAYER: Set of business process applications running on JBoss BPM Suite as the underlying BPM engine
Client layer
Since we have two different user groups (external end customer and employees) we’ve decided to develop two separate applications:
- Customer App: This app is meant to be used by our end customers (using a broad range of different mobile devices) and has therefore being implemented especially with hybrid app development principles in mind. We chose Apache Cordova (https://cordova.apache.org/) as our core development framework, which enables us to build our app against all common mobile OS with only one code base (“develop once, run everywhere” principle). In terms of the UI and application framework we decided to go for a combination of ionic (http://ionicframework.com/) and AngularJS (https://angularjs.org/). Both projects have a vibrant and active community and have been successfully adopted by many projects.
-
Employee App: This app targets remote workers (such as insurance agencies e.g.) who shall work on our processes from remote. We’ve decided to go for the same hybrid app approach in order to share code and speed up development. However, for such an end user group where we might influence the use of certain device types (such as Apple iPhone) we could have also thought about a native app (RHMAP provides an SDK for all popular mobile OS; so we could also reuse existing backend functionality in our cloud layer).
The source code of both applications is hosted on RHMAP which allows us to make use of the built-in build farm (allowing us to create push button builds for iOS, Android et al), configure and also preview the application.
Cloud layer
The cloud part of an application built with RHMAP is comprised of a so called “Cloud Code App” providing the core functionality for our clients and a set of reusable MBaaS services that enable the connectivity to 3rd party (backend) systems. The following illustration shows an overview of all components created for our showcase:
Cloud code apps
For our showcase we’ve implemented a single Node.js based app called Cloud App which accepts all incoming requests from our client layer. RHMAP provides a feature rich development framework (including custom Node.js convenience modules) making the creation of cloud code apps easy and efficient. Through the use of Node.js as our programming language we get all the benefits of its evented and asynchronous model, that works extremely well with our use case of a data intense realtime application (DIRT paradigm).
MBaaS services (Mobile backend as a service)
An MBaaS (Mobile Backend-as-a-Service) is the primary point of contact for end user applications – both mobile and web. The MBaaS hosts Node.js applications – as REST API servers and/or Express.js based web apps. The primary purpose of the MBaaS is to allow users (developers) of RHMAP to deploy Node.js server-side for their mobile apps. The MBaaS also provides functionality such as caching, persistence, data synchronization and a range of other mobile-centric functionality. Multiple MBaaS may be utilized for customer segregation and/or lifecycle management (environments).
For this showcase we’ve developed a new MBaaS connector called fh-connector-jbpm-cloud, which is meant to be reused across multiple applications hosted on RHMAP. For the use in our project we’ve instantiated it and configured the environment variables to connect to our specific JBoss BPM Suite in the backend layer.
Function wise the MBaaS connector currently provides the following functionality:
- Process management
- Start process
- Get process instance
- Task management
- Load tasks
- Load task content
- Claim task
- Complete task
- Release task
- Start task
Push notifications
We make use of the RHMAP built-in mobile push API which provides a generic way to interface with multiple push networks (Google Cloud Messaging, Apple Push Notification Service and Microsoft Push Notification Service) via REST or Node.js. This makes it very convenient to send out push notifications from 3rd party application (such as JBoss BPM Suite as demonstrated in our showcase).
More information on the push API can be found here http://docs.feedhenry.com/v3/product_features/push_notifications.html
Backend layer
This layer is comprised of a large set of different backend systems that typically run inside the datacenter of an organization; such as application servers, databases, messaging systems or ESB-like services. For the sake of this showcase we’ve chosen JBoss BPM Suite ((https://www.redhat.com/en/technologies/jboss-middleware/bpm)) as the only system in here. The BPM Suite provides a full blown authoring and runtime environment for business process applications focused on the use of open standards (such as BPMN 2.0). The included BPM engine also exposes a rich REST API that is used extensively by our MBaaS connector fh-connector-jbpm-cloud to start new process instances, control the process flow etc.
Request processing application
The core business process for our scenario is implemented as a simple BPMN 2.0 workflow that is being deployed in form of our Java based Request Processing Application.
After being instantiated the process firstly sends out a push notification to the requesting customer by simply calling the RHMAP push API. Secondly a human task called Process request is used to create a new work item in the work basket of our employees. Through our Employee App mobile application we empower remote employees to directly work on the request.
In addition to that the work items can be claimed via a traditional web-based application named Business Central, that is provided as part of JBoss BPM Suite.
Based on the decision the process completes with an according push notification to inform the customer.
More information on how to develop process applications can be found in the JBoss BPM Suite Development Guide.
B. Walkthrough
1. Customer creates new request
2. a) Employee works on request
3. b) Agency / Remote worker completes
TBD
4. Customer receives push updates on current status
C. Reference Information
Source code
The source code can be found here:
Client layer
Cloud layer
Backend layer
D. Credits
Special thanks to Sebastian Dehn (sdehn@redhat.com) for implementing large parts of the client layer.
OpenShift Quicktip: Testdriving persistent storage with NFS
Creating a persistent volume for NFS storage plugin
The administrator is responsible for creating volumes (PV). The administrator assigns some external thing (partition, entire device, NFS volume, whatever) to a PV.
- Login to OpenShift with an admin user
- Create persistent volume:
oc create -f persistent-volume-nfs.yaml
- Check status of persistent volume:
oc get pv
Creating a persistent volume claim
The end-user/developer/user/whatever is responsible for making a request for a volume (PVC). They get assigned some volume, and they don’t really know what it is. Keep in mind that there is a 1:1 mapping between PV and PVCs.
- Login to OpenShift
- Create persistent volume claim:
oc create -f persistent-volume-claim.yaml
The source code can be found on my Github page: https://github.com/sebastianfaulhaber/openshift-v3-showcase/tree/master/openshift-resources
OpenShift Quicktip: Limiting resource consumption for users
A. Resource limits
Resource limits allow you to set boundaries (max/min & default) for the compute resources a developer can define on pod/container level (see https://docs.openshift.com/enterprise/3.1/dev_guide/compute_resources.html).
- Login to OpenShift with an admin user
- Change to target project with
oc project <my-project>
- Import limit range (see https://docs.openshift.com/enterprise/3.1/dev_guide/limits.html on what options are available)
oc create -f limit-range.json
- Browse to OpenShift admin console, select the project and then “Settings”.
B. Quotas
A quota allows you to set hard limits on the overall resource consumption on project level. This is in particular useful to create a t-shirt size based accounting model (small, medium, large) for OpenShift. See also https://docs.openshift.com/enterprise/3.1/dev_guide/quota.html.
- Login to OpenShift with an admin user
- Change to target project with
oc project <my-project>
- Create quota for project:
oc create -f resource-quota.json
- Browse to OpenShift admin console, select the project and then “Settings”.
The source code can be found on my Github page: https://github.com/sebastianfaulhaber/openshift-v3-showcase/tree/master/openshift-resources
IBM WebSphere Application Server Liberty Core on OpenShift V3 Tutorial
A. Synopsis
What this is about
This project demonstrates how to use IBM WebSphere Liberty (a lightweight Java EE container comparable with Apache Tomcat) on Red Hat’s leading Platform-as-a-Service (PaaS) solution OpenShift Enterprise V3 (https://enterprise.openshift.com/. Since OpenShift is perfectly suited for running containerized workloads based on the Docker format, we could reuse the officially supported image built by IBM. Additionally we’ve added OpenShifts powerful templating mechanism in order to create a superior developer experience:
- Self-service based provisioning of new IBM WebSphere Application Server Liberty Core containers
- Existing, not yet containerized applications can simply be reused
- No prior experience with Docker needed
- Automated build & deploy life cycle
The source code can be found here: https://github.com/sebastianfaulhaber/openshift-v3-showcase/tree/master/websphere-liberty
Screenshots
B. Installation
1. Setup OSE Environment
There are multiple ways to spin up a new OpenShift environment:
All-In-One VM
This community provided Vagrant box probably provides the most convenient and fastest way to start your OpenShift developer experience. It features a complete OpenShift installation within one VM that allows you to test all aspects of a container application platform.
See for detailed instructions: http://www.openshift.org/vm/
On premise installation
The instructions for setting up an on premise installation of OpenShift Enterprise V3 can be found here: ([https://docs.openshift.com/enterprise/3.1/install_config/install/index.html]https://docs.openshift.com/enterprise/3.1/install_config/install/index.html).
OpenShift Dedicated
OpenShift Dedicated is a new offering from OpenShift Online. OpenShift Dedicated offers a hosted OpenShift 3 environment to run the containers powering your applications. This offering provides an isolated instance hosted on Amazon Web Services (AWS), providing increased security and management by the OpenShift operations team, so that you have peace of mind about the stability and availability of the platform.
See https://www.openshift.com/dedicated/
2. Enable OpenShift to run Docker images with USER in the Dockerfile
The currently provided version of IBM’s WebSphere Liberty Docker image requires the use of USER in the Dockerfile. Due to the security implications raised by USER statements OpenShift restricts the use by default. In order to make this project work, you will need to relax the security settings as described here: https://docs.openshift.com/enterprise/3.1/admin_guide/manage_scc.html#enable-images-to-run-with-user-in-the-dockerfile.
# Login to your OpenShift master via SSH
su -
oc edit scc restricted
# Change the runAsUser.Type strategy to RunAsAny
3. Import template into your OpenShift environment
wget https://raw.githubusercontent.com/sebastianfaulhaber/openshift-v3-showcase/master/websphere-liberty/websphere-liberty-template.json
oc create -f websphere-liberty-template.json -n openshift
C. User guide
1. How can I access the provided demo application?
This project provides a simple Java EE web application that can be used to verify that the showcase is working. It can be accessed after provisioning via: <YOUR_FQDN>/Sample1/SimpleServlet (e.g. http://liberty-app-http-route-demo.apps.example.com/Sample1/SimpleServlet).
2. How can I use this showcase in my own OpenShift installation?
- Create a fork of the repository in your own GIT environment
- Add your applications to the
app/folder. They will be picked up and get deployed automatically. - Specify the URL to the forked project as
SOURCE_REPOSITORY_URLwhen creating a new application. - Done.
3. How can I automate the build & deployment lifecycle
The project template comes with preconfigured OpenShift webhook triggers for Github and a generic system (see https://docs.openshift.com/enterprise/3.1/dev_guide/builds.html#webhook-triggers for more details).
In order to automate the build and deployment lifecycle you simply need to integrate the webhook URLs according to your SCM specific instructions:
- Github: https://developer.github.com/webhooks/
- Gitlab: http://doc.gitlab.com/ce/web_hooks/web_hooks.html
4. How can I view the logs of my application?
The logs can be accessed via the OpenShift Enterprise console:
Browse > Pods > YOUR_LIBERTY_POD > Logs. Alternatively you could also use the CLI command oc logs YOUR_LIBERTY_POD (https://docs.openshift.com/enterprise/3.1/cli_reference/basic_cli_operations.html#troubleshooting-and-debugging-cli-operations).
5. How can I connect to the container instance that is running my application?
You can open a terminal connection to the container via the OpenShift Enterprise console: Browse > Pods > YOUR_LIBERTY_POD > Terminal. Alternatively you could also use the CLI command oc rsh YOUR_LIBERTY_POD (https://docs.openshift.com/enterprise/3.1/cli_reference/basic_cli_operations.html#troubleshooting-and-debugging-cli-operations.
D. Reference Information
WebSphere specific
- IBM WebSphere Application Server for Developers Liberty Profile documentation
- Getting started with Liberty for Developers
- Supported Software & Hardware
OpenShift specific
E. Credits
Special thanks to Chris Eberle ceberle@redhat.com
IBM WebSphere Application Server Liberty Core on OpenShift V2 Tutorial
A. Synopsis
What this is about
We’ve created a IBM WebSphere Application Server Liberty Core cartridge in order to demonstrate the power and flexibility of Red Hat’s Open Hybrid Cloud strategy. Liberty Core provides a lightweight alternative to the classic WebSphere Application Server ND (cartridge available here: https://github.com/juhoffma/openshift-origin-websphere-cartridge) mainly targeting web applications using JEE web profile.
The cartridge currently supports the following features:
- Provisioning of new IBM WebSphere Application Server Liberty Core instances in seconds (!)
- Full build & Deploy life cycle (as with JBoss EAP cartridge)
- Hot Deployment
- Auto Scaling with web traffic
- Jenkins Integration
- Integration into JBoss Developer Studio
The source code can be found here: https://github.com/juhoffma/openshift-origin-liberty-cartridge
Screenshots
B. Installation
1. Setup OSE Environment
You have the following deployment options for this cartridge:
- OpenShift Origin developer image
- OpenShift Enterprise developer image
- Standalone installation of Red Hat OpenShift Enterprise.
2. Cartridge Installation
This cartridge does not actually ship the Liberty Profile binaries. These
have to be installed manually before this cartridge actually works. The Binaries can
be installed in 2 different ways:
- OPTION 1 – Install the Liberty Core underneath the versions directory
- OPTION 2 – Install Liberty Core outside of the cartridge context
The following sections describe the 2 different methods.
Prepare the installation
Download the required IBM WebSphere Application Server Liberty Core Installer from the IBM developer site https://developer.ibm.com/wasdev/downloads/liberty-profile-using-non-eclipse-environments/:
node# cd /opt
node# wget https://public.dhe.ibm.com/ibmdl/export/pub/software/websphere/wasdev/downloads/wlp/8.5.5.4/wlp-developers-runtime-8.5.5.4.jar
Clone the cartridge repository:
node# git clone https://github.com/juhoffma/openshift-origin-liberty-cartridge.git
Initialized empty Git repository in /opt/openshift-origin-liberty-cartridge/.git/
remote: Counting objects: 139, done.
remote: Compressing objects: 100% (103/103), done.
Receiving objects: 100% (139/139), 898.18 KiB | 1.33 MiB/s, done.
remote: Total 139 (delta 46), reused 106 (delta 15), pack-reused 0
Resolving deltas: 100% (46/46), done.
OPTION 1 – Install the Liberty Core underneath the versions directory
node# java -jar /opt/wlp-developers-runtime-8.5.5.4.jar --acceptLicense /opt/openshift-origin-liberty-cartridge/versions/8.5.5.4
Before you can use, extract, or install IBM WebSphere Application
Server for Developers V8.5.5, you must accept the terms of
International License Agreement for Non-Warranted Programs and
additional license information. Please read the following license
agreements carefully.
The --acceptLicense argument was found. This indicates that you have
accepted the terms of the license agreement.
Extracting files to /opt/openshift-origin-liberty-cartridge/versions/8.5.5.4/wlp
Successfully extracted all product files.
OPTION 2 – Install Liberty Core outside of the cartridge context
Binary installation
You can also install IBM WebSphere Application Server Liberty Core outside of the cartridge and
define the location using a node level variable like you can do with the full
WebSphere cartridge.
To make this work all you have to do is to create the file
/etc/openshift/env/OPENSHIFT_LIBERTY_INSTALL_DIR and put the installation location into
it. See the Official Documentation for an example on how to configure node level variables.
Customize SELinux Configuration
Since IBM WebSphere Application Server Liberty Core is installed outside of the gear’s sandbox, you need to customize SELinux permission settings in a way that the installation directory “/opt/IBM/
As a workaround and/or for testing purposes you could also temporarily disable SELinux policy enforcement:
setenforce 0
Install and activate the cartridge
node# oo-admin-cartridge --action install -s /opt/openshift-origin-liberty-cartridge --mco
1 / 1
vm.openshift.example.com
output: install succeeded for /opt/openshift-origin-liberty-cartridge
Finished processing 1 / 1 hosts in 3174.10 ms
broker# oo-admin-ctl-cartridge -c import-node --activate --obsolete --force
Importing cartridges from node 'vm.openshift.example.com'.
Updating 26 cartridges ...
54f62e57e659c5cd31000001 # U mysql-5.5 (active)
54f62e57e659c5cd31000002 # U mysql-5.1 (active)
54f62e57e659c5cd31000003 # U jenkins-1 (active)
54f62e57e659c5cd31000004 # U nodejs-0.10 (active)
54f62e57e659c5cd31000005 # U haproxy-1.4 (active)
54f62e57e659c5cd31000006 # U jbosseap-6 (active)
54f62e57e659c5cd31000007 # U jbossews-2.0 (active)
54f62e57e659c5cd31000008 # U jbossews-1.0 (active)
54f62e57e659c5cd31000009 # U php-5.4 (active)
54f62e57e659c5cd3100000a # U php-5.3 (active)
54f62e57e659c5cd3100000b # U mongodb-2.4 (active)
54f62e57e659c5cd3100000c # U postgresql-9.2 (active)
54f62e57e659c5cd3100000d # U postgresql-8.4 (active)
54f62e57e659c5cd3100000e # U python-3.3 (active)
54f62e57e659c5cd3100000f # U python-2.7 (active)
54f62e57e659c5cd31000010 # U python-2.6 (active)
54f62e57e659c5cd31000011 # U perl-5.10 (active)
54f62e57e659c5cd31000012 # U diy-0.1 (active)
54f62e57e659c5cd31000013 # U jenkins-client-1 (active)
54f62e57e659c5cd31000014 # U ruby-1.8 (active)
54f62e57e659c5cd31000015 # U ruby-1.9 (active)
54f62e57e659c5cd31000016 # U ruby-2.0 (active)
54f62e57e659c5cd31000017 # U amq-6.1.1 (active)
54f62e57e659c5cd31000018 # U cron-1.4 (active)
54f62e57e659c5cd31000019 # U fuse-6.1.1 (active)
54f62e57e659c5cd3100001a # A hoffmann-liberty-8.5.5.4 (active)
Make sure you see the line reporting the cartridge 54f62e57e659c5cd3100001a # A hoffmann-liberty-8.5.5.4 (active)
broker# oo-admin-broker-cache --clear; oo-admin-console-cache --clear
C. Reference Information
WebSphere specific
- Getting started with Liberty for Developers
- Supported Software & Hardware
- IBM Information Center
- Command port needs to be disabled
OpenShift specific
JBoss Operations Network Showcase
A. Synopsis
What this is about
This demo project showcases some of the most common use cases regarding JBoss Operations Network, Red Hat’s leading enterprise middleware systems management tooling (more information on JON can be found here: http://www.redhat.com/de/technologies/jboss-middleware/operations-network).
- Automated provisioning of resources (e.g. JBoss Enterprise Application Platform)
- Integration of custom JMX MBeans into JON
The resources provided with this showcase are intended as a starting point and shall help you to setup these use cases in your own JBoss Operations Network environment.
Screenshots – Automated provisioning of resources
Screenshots – Integration of custom JMX MBeans
B. Base installation and prerequisites
1. JBoss Operations Network (JON)
Follow the official installation instructions for JON V3.3 here: https://access.redhat.com/documentation/en-US/Red_Hat_JBoss_Operations_Network/3.3/html/Installation_Guide/index.html
2. Apache Maven
You will need to install Apache Maven for building the source code for this showcase. Please follow the installation instructions here: http://maven.apache.org/download.cgi
C. Use Case – Automated provisioning of resources
1. Benefits
This use case describes how to create a standardised JBoss Enterprise Application Platform (EAP) installation package. In terms of JON this is a so called “Bundle”. This Bundle can then be provisioned to a target system (or even multiple) in a highly automated fashion.
More information on the provisioning features can be found in the official JON documentation: https://access.redhat.com/documentation/en-US/Red_Hat_JBoss_Operations_Network/3.3/html/Users_Guide/part-Deploying_Applications_and_Content.html.
2. Showcase components
- eap-bundle – This project provides the core ingredients for creating a bundle to provision instances of JBoss Enterprise Application Platform V6.3.
3. Installation
- Create Bundle Group “JBoss EAP V6 Base Installation”
-
Define a new bundle
-
Deploy the bundle to a target system
-
Import the newly created EAP instance into JON inventory
-
Configure connection settings
-
Start the server
D. Use Case – Integration of custom JMX MBeans
1. Benefits
It is a very common scenario that your applications have been enhanced with MBeans for management, runtime configuration or even monitoring capabilities. JBoss Operations Network allows you to integrate these MBeans into its management environment, which actually means that you can then leverage JON’s full systems management and monitoring capabilities:
– Historical monitoring of your MBeans
– Dashboarding and alerting
– Execution of MBean operations
2. Showcase components
- helloworld-mbean – JEE application that shows different ways of exposing MBeans (taken from EAP quickstarts at https://github.com/jboss-developer/jboss-eap-quickstarts/).
- custom-jmx-plugin – JBoss Operations Network Agent plugin that integrates custom MBeans (provided by helloworld-mbean) via JMX into JON’s monitoring & dashboarding.
3. Installation
1. Build and deploy the MBean provider application
Build the application with Maven:
# OPTIONAL: Copy the provided settings.xml to your local maven conf dir
cp https://raw.githubusercontent.com/sebastianfaulhaber/jon-demo/master/doc/settings.xml ~/.m2/
# Start the build
cd ./helloworld-mbean
mvn clean install
# Hot deploy the application to an instance of JBoss EAP
# you could use the instance that has been provisioned in the use case "Automated provisioning of resources"
cp ./helloworld-mbean-webapp/target/jboss-helloworld-mbean-helloworld-mbean-webapp.war <EAP_INSTALLATION_DIR>/standalone/deployments
2. Build and deploy the agent plugin
Build the application with Maven:
# OPTIONAL: Copy the provided settings.xml to your local maven conf dir
cp https://raw.githubusercontent.com/sebastianfaulhaber/jon-demo/master/doc/settings.xml ~/.m2/
# Start the build
cd ./custom-jmx-plugin
mvn clean install
Deploy the agent plugin:
cp ./target/custom-jmx-plugin-1.0-SNAPSHOT.jar <JON_SERVER_INSTALL_DIR>/plugins/
The JON server periodically scans the “plugins” directory for updates and will pickup the agent plugin after some time, which is finally pushed to the connected JON agents. The agents might need to be restarted to detect the plugin after initial installation.
In the end you should see a service group called “Myapp Services” that contains the applications’ MBeans. You can now start to add the contained metrics to custom dashboard, define alerts on it and so on.
Z. Appendix
The source code can be found here: https://github.com/sebastianfaulhaber/jon-demo
Demonstration of IBM WebSphere Application Server on OpenShift V2
I’ve recorded a small demonstration video showing the OpenShift V2 cartridge:
Cheers,
Sebastian
IBM WebSphere Application Server on OpenShift V2 Tutorial
A. Synopsis
What this is about
We’ve created a IBM WebSphere Application Server cartridge in order to demonstrate the power and flexibility of Red Hat’s Open Hybrid Cloud strategy. The main focus for this cartridge is OpenShift Enterprise (https://www.redhat.com/de/technologies/cloud-computing/openshift.
The cartridge currently supports the following features:
- Provisioning of new IBM WebSphere Application Server instance in minutes
- Full build & Deploy life cycle (as with EAP cartridge)
- Hot Deployment
- Jenkins Integration
- Integration into JBoss Developer Studio
The source code can be found here: https://github.com/juhoffma/openshift-origin-websphere-cartridge
Screenshots
B. Installation
1. Setup OSE Environment
You have the following deployment options for this cartridge:
- OpenShift Origin developer image http://openshift.github.io/documentation/oo_deployment_guide_vm.html
- OpenShift Enterprise developer image https://rhn.redhat.com/rhn/software/channel/downloads/Download.do?cid=21355
- Standalone installation of Red Hat OpenShift Enterprise.
2. WebSphere Application Server Installation
IMPORTANT NOTES
In contradiction to the deployment model of other cartridges (that includes all binaries of a certain technology), we’ve decided not to put the installation files into the cartridge. The reasoning behind:
- IBM WebSphere Application Server Binaries are very large (around 2-3 GB)
- Installation process for the binaries takes takes a long time (up to 15 minutes according to the computing resources)
Binary Installation
The following steps will take you through the installation steps for IBM WebSphere Application Server for Developers:
# Install Installation Manager + WebSphere Application Server for Developers
unzip DEVELOPERSILAN.agent.installer.linux.gtk.x86_64.zip
# Replace install.xml
# You can find a sample "install.xml" here https://github.com/juhoffma/openshift-origin-websphere-cartridge/tree/master/usr/doc/install.xml
# Create key files (for connection to IBM download site)
cd tools
touch secureStorage
touch masterPassword
vi masterPassword
# Insert your own IBM ID
./imutilsc saveCredential -passportAdvantage -userName <IBMID_USERNAME> -userPassword <IBMID_PASSWORD> -secureStorageFile ./secureStorage -masterPasswordFile ./masterPassword
# Start installation (you must be root)
su -
./installc -log /tmp/ibm_installation_manager.log -acceptLicense -masterPasswordFile ./tools/masterPassword -secureStorageFile ./tools/secureStorage
Non-Root permissions
In order to create profiles by non-root users, special file permission settings have to be set on your WebSphere installation. Please follow the steps described here: http://www-01.ibm.com/support/knowledgecenter/SS7JFU_8.5.5/com.ibm.websphere.express.doc/ae/tpro_nonrootpro.html?lang=en
Installation Result
After successfully executing the above steps you have installed the following components:
- IBM Installation Manager – /opt/IBM/InstallationManager
- WebSphere Application Server – /opt/IBM/WebSphere/AppServer
3. Customize SELinux Configuration
Since IBM WebSphere Application is installed outside of the gear’s sandbox, you need to customize SELinux permission settings in a way that the installation directory “/opt/IBM/WebSphere/AppServer” can be accessed with read/write.
As a workaround and/or for testing purposes you could also temporarily disable SELinux policy enforcement:
setenforce 0
4. Cartridge Installation
The cartridge can be installed as any other OSE cartridge. However, you MUST have to make sure that WebSphere Application Server has been installed before (as described in the preceding sections):
On each OpenShift node execute the following commands:
cd /usr/libexec/openshift/cartridges
git clone https://github.com/juhoffma/openshift-origin-websphere-cartridge.git
oo-admin-cartridge --action install --recursive --source /usr/libexec/openshift/cartridges
oo-admin-ctl-cartridge --activate -c import-node --obsolete
oo-admin-broker-cache --clear && oo-admin-console-cache --clear
B. Administration and configuration
Configure a custom installation location for IBM WebSphere Application Server
This cartridge needs an existing installation of the WebSpehere Application Server on each of your nodes. You need to define the location of the installation through a system wide environment variable
echo "/opt/IBM/WebSphere/AppServer" > /etc/openshift/env/OPENSHIFT_WEBSPHERE_INSTALL_LOCATION
this will make sure that the cartridge finds the necessary components.
Configure non-root file permissions
The file permissions of your WebSphere installation must be set to allow non-root profile creation (see official IBM documentation: http://www-01.ibm.com/support/knowledgecenter/SS7JFU_8.5.5/com.ibm.websphere.express.doc/ae/tpro_nonrootpro.html?lang=en). This has to be done once per binary installation. You can use the following script as a basis for automating this: “usr/setWebSpherePermissionsForNonRootProfileCreation.sh”
How profile creation works
This cartridge will call ${OPENSHIFT_WEBSPHERE_DIR}/install/bin/manageprofiles.sh and create a profile with the name ${OPENSHIFT_APP_NAME}. The profile will be created underneath the profile directory inside your gears data directory.
The profile will have security enabled. An admin username and a password are generated at the time of creation and the PerfTuningSetting will be set to development.
Access to WebSphere Admin Console
PREFFERED – Option 1) After you have created your gear, do a rhc port-forward <GEAR_NAME> and open a browser with the following URL https://<YOUR_LOCAL_IP>:9043/ibm/console.
Option 2) The Admin Console is also exposed via a separate external port that can be determined as follows:
rhc ssh <GEAR_NAME>
export | grep WC_ADMINHOST_SECURE_PROXY_PORT
Now point your browser to the following URL: https://<GEAR_DNS>:<WC_ADMINHOST_SECURE_PROXY_PORT>/ibm/console/logon.jsp and enter your credentials. Unfortunately the Admin Console tries to redirect us to the local port 9043. That is why we have to enter the following URL manually: https://<GEAR_DNS>:<WC_ADMINHOST_SECURE_PROXY_PORT>/ibm/console/login.do?action=secure.
Hot Deployment
Hot Deployment is accomplished by using WebSphere’s “Monitored Directory Deployment” feature (see official documentation here: http://www-01.ibm.com/support/knowledgecenter/SS7JFU_8.5.5/com.ibm.websphere.express.doc/ae/urun_app_global_deployment.html?lang=en). In order to deploy an EAR just put it in the following directory: app-root/data/profile/monitoredDeployableApps/servers/server1.
In addition to this you can also Jenkins as a build server for your application. Just login to your OpenShift Console, select your WebSphere application and click Enable Jenkins. This will create a new Jenkins job for your application that will be triggered after each GIT push to your OpenShift instance.
C. Reference Information
WebSphere specific
- Command reference “manageprofiles.sh”
- Disable Security HTTPS for Web App
- Configure WebSphere to bind to specific IP
- WebSphere Global Deployment Settings
- WebSphere Auto Deployment
- File Permissions for non-admin install
OpenShift specific
Typo3 Extension Source Code now on Github
I’ve begun to upload the source code of my Typo3 extensions to Github:
